Sacmi in china: our companies


SACMI NANHAI


SACMI SHANGHAI


SACMI HONG KONG

THE WHOLE COMPANY CONSISTS OF

31,000 m2

a 31,000 m2 workshop

2,000 m2

a 2,000 m2 warehouse/technical services facility

1,500 m2

1,500 m2 of offices

our special products for chinese market

  • Max pressing force kN 82000
    Clearance mm 2.450
    Max plunger stroke mm 230
    Effective ejector stroke mm 74
    Maximum ejector force SPE kN 150
    Installed power in motors kW 212
    Oil quantity for hydraulic system Lt/td> 2.500
    Number of cycles up to /min 16
    Oil cooling water (20°C) lt 105/min
    Total net weight ton 183


  • Max pressing force kN 75.000
    Clearance between columns mm 2.450
    Max filling length mm 1340
    Max plunger stroke mm 230
    Effective ejector stroke mm 74
    Maximum ejector force kN 150
    Installed power in motors kW 212
    Oil quantity for hydraulic system Lt/td> 2.200
    Number of cycles up to /min 16
    Oil cooling water (20°C) lt 105/min
    Total net weight ton 175


  • Max pressing force kN 64000
    Clearance mm 2450
    Working width mm 2275
    Max loading depth mm 990
    Weight t 152


  • Max pressing force kN 51.000
    Clearance between columns mm 1.750
    Max filling length mm 1100
    Max plunger stroke mm 185
    Effective ejector stroke mm 74
    Maximum ejector force kN 150
    Installed power in motors率 kW 211
    Oil quantity for hydraulic system Lt/td> 1.300
    Number of cycles up to /min 11
    Oil cooling water (20°C) lt 105/min
    Total net weight ton 84.6


  • Max pressing force kN 42.000
    Clearance between columns mm 1.750
    Max plunger stroke mm 185
    Effective ejector stroke mm 74
    Maximum ejector force kN 150
    Installed power in motors kW 118
    Optional die heating kW/td> 50
    Oil quantity for hydraulic system Lt 1.200
    Number of cycles up to /min 20
    Oil cooling water (20°C) lt 60
    Total net weight ton 80


  • Max pressing force kN 35.000
    Clearance between columns mm 1.750
    Max plunger stroke mm 180
    Effective ejector stroke mm 74
    Maximum ejector force kN 150
    Installed power in motors kW 98
    Oil quantity for hydraulic system Lt 1.200
    Oil cooling water (20°C) lt 50/min
    Total net weight ton 64


  • Max pressing force kN 30.000
    Clearance between columns mm 2.250
    Max plunger strokes mm 180
    Effective ejector stroke mm 74
    Maximum ejector force kN 150
    Installed power in motors kW 97.5
    Oil quantity for hydraulic system Lt 1200
    Oil cooling water (20°C) lt 50/min
    Total net weight ton 74


  • Max pressing force kN 27.500
    Clearance between columns mm 1.750
    Max plunger stroke mm 160
    Effective ejector stroke mm 90
    Maximum ejector force kN 110
    Installed power in motors kW 98
    Optional die heating kW 24
    Oil quantity for hydraulic system Lt 1.100
    Number of cycles up to /min 22
    Oil cooling water (20°C) lt 50/min
    Total net weight ton 55


Name Max pressing force (kN) Opening (mm) Working width (mm) Max loading depth (mm) Crossbeam depth (mm) Installed electric power (kW) weight (t)
PHC2890 27.500 1750 1595 900 880 97.5 52
PCH3020 30.000 2250 2085 900 850 97.5 73.6
PHC3500 35.000 1750 1595 990 900 97.5 64
PHC4300 42.000 1750 1595 1110 1100 117.5 80
PHC5211 51.000 1750 1595 1110 1110 211 84.6
PHC6500 64.000 2450 2275 990 152
PHC7500 75.000 2450 2275 1340 1300 211 176
PHC8200 82.000 2450 2275 1340 1300 211 182

PHC RED EDITION

The Red Edition® family, consisting of the fastest presses on the market, is here.
Connectivity, efficient use of power. Perfect for large product sizes.

WATCH THE VIDEO

CONTINUA+ COMPACTION TECHNOLOGY FOR SLABS AND TILES

The benchmark technology for variable-size, variable-thickness slab and tile manufacturing.

S D P - SACMI DIGITAL PRINTER

SDP is the digital printer designed for the Eastern market, equipped with a patented new-generation ink supply system, compatible with all available fluids
The printing system is modular: modules can be extended from 8 up to 16 bars. To complete the range there is also a 2-bar module for the application of structuring inks (shape inks) or material effects.
SDP, like the rest of the SACMI digital printer family, can be integrated with DDG for the coordinated application of glue and selective grit to create unparalleled three-dimensional aesthetic effects.

LITHIUM-ION BATTERY POWDER TREATMENT

ANODE AND CATHODE MATERIALS

Continuous powder treatment in gastight roller hearth furnace and indirectly heated rotary furnace.

DISCOVER MORE

SACMI, service on your side

For Sacmi, providing services is a key part of completing the sale of production lines.
That is why the Group has created its Global Network, which includes more than 70 companies, on every continent, offering customer care over the phone, on the internet or through after sales support programmes, with regular visits from dedicated personnel who help the customers to run, maintain and get the most out of their production lines.

Read more

SACMI, service on your side
